DC Motor Temperature Guide: How to Keep Your Small Motors Running Cool

Theo Raines in Tech & Innovation June 2025 • 4 min read.

"Discover how temperature affects the performance of small brushed DC motors and learn practical tips to prevent overheating and extend their lifespan."

Small brushed DC motors are ubiquitous in countless applications, from consumer electronics to industrial machinery. While these motors are known for their simplicity and reliability, they are susceptible to thermal damage. Overheating can lead to irreversible issues such as demagnetization and short circuits, significantly reducing motor lifespan and performance.

Understanding the factors that contribute to temperature rise in DC motors is essential for engineers and hobbyists alike. By monitoring the temperatures of sensitive components and implementing effective cooling strategies, you can prevent thermal damage and optimize motor performance. This guide provides practical insights into the temperature dynamics of small brushed DC motors under varying loads.

In this article, we’ll explore the key aspects of temperature management in small DC motors. We will cover the primary causes of heat generation, methods for measuring temperature changes, and strategies for dissipating heat to maintain optimal operating conditions. Whether you're designing a new application or troubleshooting an existing motor, this guide will equip you with the knowledge to keep your motors running cool and efficiently.

Why Does Temperature Matter for Small DC Motors?

DC Motor Temperature Control Illustration

The performance and longevity of small DC motors are significantly affected by temperature. Excessive heat can cause several problems:

Thermal Damage: Overheating can melt or burn the winding insulation, leading to short circuits. It can also demagnetize the permanent magnets, weakening the motor's torque and efficiency. Li Yan et al. [1] noted that high internal motor temperatures weaken the characteristics of permanent magnet materials, increasing rotor bearing fatigue and reducing motor efficiency.

Reduced Efficiency: As motor temperature increases, its efficiency decreases due to increased electrical resistance and energy losses.
Decreased Lifespan: Prolonged exposure to high temperatures accelerates the wear and tear on motor components, shortening its operational life.
Performance Issues: Overheating can cause inconsistent performance, leading to reduced torque and speed, which can affect the overall application.

Generally, small DC motors are used in low-voltage applications (12-24V). Managing their thermal behavior, especially heat transfer and dissipation, is critical. When the motor runs, it dissipates heat through copper losses, iron losses, mechanical losses, and stray losses. Copper losses, as shown in Equation 1, are a significant factor:

Key Takeaways for Keeping Motors Cool

Managing the temperature of small DC motors is essential for maintaining their performance and extending their lifespan. The brush typically experiences the highest temperature rise, followed by the bearing, casing, and permanent magnet. Monitoring these components and understanding how different loads affect temperature can help prevent overheating and ensure efficient operation.
