Future of Fiber: How FSR-Free Modulators Could Revolutionize Data Transmission

Mira Elwood in Tech & Innovation August 2025 • 4 min read.

"Breaking the Bandwidth Barrier: The Innovative Microring Modulator Design Poised to Transform WDM Systems"

In today's world, where data is king, the demand for higher bandwidth and faster data transmission speeds is ever-increasing. Wavelength division multiplexing (WDM) systems, which use Mach-Zehnder Interferometer (MZI)-based modulators, are a common solution, but they often come with limitations in terms of footprint and the need for wavelength multiplexers.

Microring (MRR) modulators offer a promising alternative. By coupling an array of modulators to a common bus waveguide, each modulator can selectively modulate a specific wavelength channel. This simplifies the WDM architecture and reduces the system's overall footprint, making it a more efficient solution.

However, current MRR-based WDM transmitters face a significant challenge: the free spectral ranges (FSRs) of the MRRs limit the aggregate data rate. To overcome this hurdle, researchers have been exploring various solutions, including extended-FSR MRR filters and FSR-free MRR filters using contra-directional-couplers (contra-DCs).

What Makes This New Microring Modulator a Game-Changer?

Surreal digital illustration of interconnected light pathways in a silicon chip.

In response to the limitations of current technologies, a novel FSR-free MRR modulator design has emerged, integrating a bent, contra-DC to couple light into and out of the modulated cavity. This innovative approach achieves FSR-free amplitude and phase responses at its through port, effectively eliminating the free spectral range and paving the way for higher data transmission rates.

To further enhance the modulator's performance and compensate for potential fabrication variations, a two-point coupling scheme to a secondary bus is incorporated. This allows for precise tuning of the modulator's bandwidth (BW) and extinction ratio (ER), ensuring optimal device performance.

FSR-Free Operation: Eliminates spectral range limitations, enabling more channels and higher data rates.
Bent Contra-Directional-Coupler: Couples light into and out of the cavity, achieving FSR-free amplitude and phase responses.
Two-Point Coupling Scheme: Tunes bandwidth and extinction ratio for optimal performance.

The design of this modulator involves careful consideration of various parameters. The bent contra-DC, for example, is designed assuming rib waveguides with specific slab and rib heights. The average widths of the grating bus waveguide and grating ring waveguide, as well as the radius of curvature of the ring grating waveguide and the corrugations' grating period, are all optimized to achieve the desired performance.

The Future of Data Transmission is Here

The development of this FSR-free modulator represents a significant step forward in optical communication technology. By eliminating the limitations imposed by free spectral ranges, this innovation paves the way for higher data rates and more efficient WDM systems. While further research and development are needed, the potential impact of this technology on the future of data transmission is undeniable.

About this Article -

This article was crafted using a human-AI hybrid and collaborative approach. AI assisted our team with initial drafting, research insights, identifying key questions, and image generation. Our human editors guided topic selection, defined the angle, structured the content, ensured factual accuracy and relevance, refined the tone, and conducted thorough editing to deliver helpful, high-quality information.See our About page for more information.

This article is based on research published under:

DOI-LINK: 10.1109/group4.2018.8478723, Alternate LINK

Title: Fsr-Free Microring-Based Modulator

Journal: 2018 IEEE 15th International Conference on Group IV Photonics (GFP)

Publisher: IEEE

Authors: Ajay Mistry, Mustafa Hammood, Hossam Shoman, Lukas Chrostowski, Nicolas A. F. Jaeger

Published: 2018-08-01

Everything You Need To Know

What is the main challenge that current Microring (MRR) modulators face in Wavelength Division Multiplexing (WDM) systems?

Current Microring (MRR)-based WDM transmitters are limited by their free spectral ranges (FSRs). The FSRs restrict the total data rate. This is a significant drawback because it limits the number of wavelength channels and the overall speed at which data can be transmitted. Traditional Mach-Zehnder Interferometer (MZI)-based modulators, while also used in WDM systems, have their own drawbacks, such as larger footprints and the need for wavelength multiplexers, making MRRs a promising alternative if the FSR limitations can be overcome.

How does the FSR-free Microring Modulator design overcome the limitations of traditional MRR modulators?

The novel FSR-free Microring Modulator design integrates a bent contra-directional-coupler (contra-DC). This component is crucial because it couples light into and out of the modulated cavity. The use of the bent contra-DC is essential to achieve FSR-free amplitude and phase responses at its through port, effectively eliminating the free spectral range. This design allows for more channels and higher data rates, which is a significant improvement over traditional MRR modulators and enhances the capabilities of WDM systems.

What is the role of the two-point coupling scheme in the FSR-free modulator design, and why is it important?

The two-point coupling scheme in the FSR-free modulator design is used to tune the bandwidth (BW) and extinction ratio (ER) of the modulator. This is crucial for optimizing the device's performance. By precisely controlling these parameters, the design can compensate for variations that may occur during fabrication. Accurate tuning ensures that the modulator operates at its best possible efficiency, maximizing data transmission rates and minimizing signal loss in the WDM system.

Could you explain the key components and design considerations of the FSR-free Microring Modulator?

The design hinges on several key components and parameters. Firstly, the bent contra-directional-coupler (contra-DC) is used to couple light into and out of the cavity, enabling the FSR-free operation. The design carefully considers the rib waveguides, with specific slab and rib heights, as well as the average widths of the grating bus waveguide and the grating ring waveguide. The radius of curvature of the ring grating waveguide and the corrugations' grating period are also optimized to achieve the desired performance of the modulator. These parameters all contribute to the modulator's ability to operate effectively in WDM systems.

What are the broader implications of this FSR-free modulator for the future of data transmission, and how does it compare to other technologies like MZI-based modulators?

The development of this FSR-free modulator represents a significant step toward higher data rates and more efficient WDM systems. By eliminating spectral range limitations, this modulator promises to revolutionize data transmission. This innovation offers advantages over traditional Mach-Zehnder Interferometer (MZI)-based modulators, particularly in terms of footprint and the need for wavelength multiplexers. However, both technologies have their own strengths and weaknesses. While further research and development are needed, this FSR-free modulator has the potential to significantly impact the future of data transmission by enabling faster and more efficient data transfer in optical communication systems.
